AN 01-25CN-2             PARAGRAPH 1

SECTION IV
MAJOR COMPONENT PARTS AND INSTALLATION
Remove the bolt which attaches the lower end of the elevator stop to the match angle.

     (q) Disconnect the gun trigger and hydraulic motor electrical conduit at base of the control stick.

     (r) Remove the two bolts which attach the control stick torque tube forward fittings to the match angles and remove the control stick assembly.

     (s) Remove the heating and ventilating control rod.

     (t) Remove all bolts through the match angles and separate the wings. (The center line bulkhead is attached to and will remain with the right panel.)(See Fig. 30.) 		         (3) TO DISASSEMBLE THE WING PANELS:

     (a) TO REMOVE THE WING TIP: - Remove the row of screws around the contour at the inboard end of the wind tip.

NOTE
Pull the wing tip outboard until sufficient clearance can be obtained to disconnect the electrical wires to the navigation light.

     (b) TO REMOVE THE AILERON:
       1. Remove the bonding.
       2. Remove the one bolt at the center hinge
